F-Class Retrofit & Remodeler

Grow your bottom line by turning 50-75% of your current lighting operating costs into profit with Vantage Lighting’s high-performance family of F-Class Gen V and Commercial LED retrofit and remodeler kits. Replacing decades-old lighting systems in your facility is a great way to significantly reduce operating and maintenance costs, including revenue losses resulting from associated building occupancy interruptions. Manufactured in the U.S., the F-Class family is easy to procure, easy on the budget, and can be on the job site in days, not weeks.

TWO-GRADES
Commercial & Architectural

F-Class Commercial Retrofits & Remodelers are available up to 2000 lumens in 3000, 3500 or 4000 Kevlin temperatures. F-Class Gen V Retrofits & Remodelers are available up to 5000 lumens in 2700 - 5000 Kelvin and offer a variety of dimming options. Both F-Class Commercial & F-Class Gen V Retrofit & Remodelers are available in easy-to-install kits for 4", 6", 8" and 10" aperture sizes.

LED Cylinders

EASY 4 STEP INSTALLATION
F-Class Commercial Retrofit Kit shown below

Install clips to existing vertical or horizontal flanged frames. Vantage Retrofit & Remodeler Kits come standard with short V-Clips for existing vertically flanged housings (shown in illustration) and longer L-Clips for existing horizontally flanged housings.

Capela Series

Step 1

Remove the existing reflector and disconnect the power supply.

Capela Series

Step 2

Install clips to existing vertical or horizontal frames.

Capela Series

Step 3

Wire the F-Class Commercial Retrofit Kit leads to the leads from the existing junction box.

Capela Series

Step 4

Insert the light engine, driver, and reflector assembly through the existing hole in the ceiling, making sure it engages with the clips for proper retention.
